110KW-Powered PP Strap Making Machine With 260-300m/Min Running Speed
Technical Parameters of PP strip making line
| Model |
PP-2 |
PP-4 |
PP-6 |
| Production material |
recycled materials/New raw materials |
recycled materials/New raw materials |
recycled materials/New raw materials |
| Number of strips produced |
2 |
4 |
6 |
| Output bandwidth (mm) |
5-19mm |
5-19mm |
5-19mm |
| Tape thickness (mm) |
0.4-1.2 |
0.4-12 |
0.4-12 |
| Extrusion volume (kg/h) |
100-120 |
230-260 |
250-380 |
| Maximum linear speed(m/min) |
≥260 |
≥260 |
≥260 |
| PLC control system |
PLC |
PLC |
PLC |
| Screw model |
90 |
110 |
125 |
| Reducer model |
200 |
220 |
250 |
Features of PP Belt Production Line
Multi-strip Parallel Extrusion Structure
The PP strapping production line adopts a parallel extrusion design with 2–12 strips, enabling continuous production. Under 24-hour operating conditions, different models have a capacity range of 2.5–14 tons. Models with 1–12 strips extruding simultaneously can be selected based on production needs.
High-Speed Operation Supports High-Frequency Orders
The equipment's line speed can reach ≥260–300 m/min, reducing production queues under stable operating conditions and adapting to high-frequency shipping scenarios such as warehousing logistics and export packaging.
Supports Recycled and Blended Material Processing
The equipment supports the processing of virgin polypropylene (PP), recycled materials, and blends, helping companies achieve a balance between cost control and material utilization.
Stable Dimensional Output Mechanism
Through the cooperation of a five-roller traction system and a circulating cooling system, the strapping maintains a stable dimensional range during the forming process:
Width: 5–19 mm
Thickness: 0.3–1.2 mm
This structure helps reduce dimensional deviations caused by material fluctuations.
PP & PET Packaging Strapping Introduction & Differences
PP packaging strapping (Polypropylene) is a cost-effective, versatile and easy-to-use packaging material. It is widely used in logistics, warehousing and transportation, offering economical solutions for light to medium-duty bundling.
PET packaging strapping (Polyethylene Terephthalate) is a new generation of high-strength, eco-friendly strapping. With better tensile strength and stability, it gradually replaces steel strapping and is ideal for heavy-duty, long-distance transportation and high-load bundling.
Main differences:
PP strapping: cost-effective, lightweight, suitable for light cargoes packing.
PET strapping: higher strength, better durability, ideal for heavy goods and secure transport.
FAQ
Q: What about the payment terms?
----Always 30% down payment as deposit,70% balance payment after inspection before shipping.
Q: What is your guarantee time?
----Our guarantee time is 12 months.
Q: If you will send engineer coming to our factory to install and test the machines?
----Yes,Every set of machine we will send professional engineer to your factory and help installation and test the machines for you.
Q: If you have CE,SGS,ISO certificate?
----Yes,except these,if you also need other certificates,we also can help to apply.
Q: If we buy your machines, can you offer us wear-out spare pats?
----Yes,We provide our high quality machine 1 years' guarantee,and we will also offer you 1 years wear-out spare parts for free.Once your machines broken or doesn't work within 1 years and you can't solve it, firstly, we will try to help you to find problems from your words description by phone or other communication tools. Secondly, if the phone solutions still not work, our engineers will go to your factory to solve it. Meanwhile, they will teach you the related experiences for fixing.
